12 Channel Audio Mixer (YAMAHA) MG12

Up to 4 microphones / 10 line inputs (4 mono + 3 stereo)
1 stereo bus
1AUX (including FX)
"D-PRE" speaker, with a reverse transistor circuit
Single knob compressor
Advanced effects: SPX, with 24 sets of preset effects
24-bit / 192kHz 2 in / out USB audio function
Connect to iPad (2 or higher) via Apple iPad Camera Connection
Kit / Lightning to USB Camera Adapter (connection adapter)
Cubase Al DAW download software
PAD switch on mono input channel
+ 48V phantom power supply
XLR balanced output
Metal body

Datasheet

Get Quotation

DETAILS

SPECS

Specifications of 12 Channel Audio Mixer (YAMAHA)

Model		MG20XU/MG20		MG16XU/MG16		MG12XU/MG12
Frequency response	Enter to STEREO OUT	+0.5dB/-1.5dB (20Hz to 48kHz), Reference rated output level @ 1kHz, GAIN knob: Min
Total harmonic distortion（THD+N）	Enter to STEREO OUT	0.03 % @ +14dBu (20Hto20kHz), GAIN knob: minimum 0.005% @ + 24dBu (1kHz), GAIN knob: minimum
Hum and noise*1 (20Hzto20kHz)	Same input noise	-128dBu(Mono input channel, Rs: 150Ω, GAIN knob: max)
	Residual output noise	-102dBu(STEREO OUT, STEREO Main fader: minimum）
Crosstalk（1kHz) *2		-78dB
Input channel	Mono	12			8		4
	Mono/Stereo [MIC/LINE]	4			2		2
	Stereo [LINE]	0			2		2
Input channel	STEREO OUT	2
	MONITOR OUT	1
	PHONES	1
	Channel Gain	4			4		2
	3-band EQ	4			4		2
Bus bar		stereo: 1, Grouping: 4, AUX: 4(MG20XU: include FX>		stereo: 1, Grouping: 4, AUX: 4(MG16XU: in		stereo: 1, Grouping: 2, AUX: 2(MG12XU: include FX)
Input channel function	PAD (Mono)	26dB
	HPF (Mono, Mono/Stereo)	80Hz, 12dB / octave (Mono / Stereo: MIC only)
	COMP (Mono)	Single-knob compressor (gain / threshold / ratio) threshold: +22 dBu to -8dBu, ratio: 1: 1 to 4: 1, output level: 0dB to 7dB attack time: about 25msec, release time: about 300msec
	EQ	HIGH: Gain: + 15dB / -15dB, Frequency: 10 kHz Slope
		MID: Gain: + 15dB / -15dB, Frequency: Mono 250Hz - 5kHz peak Stereo 2.5 kHz peak		MID: gain: + 15dB / -15dB, frequency: 2.5kHz peak
		LOW: Gain: + 15dB / -15dB, frequency: 100Hz slope
	PEAK LED (Mono)	The LED lights up when the post EQ signal reaches 3dB below the frame distortion
Level meter	Before listening LEVEL	2x12 - dot pitch LED level meter [PEAK, +10, +6, +3, 0, -3, -6, -10, -15, -20, -25, -30dB]
Built-in digital effects (XU model)	SPX algorithm	24 programming, PARAMETER controller: 1, FOOT SW: 1 (FX RTN CH on / off)
USB audio (XU model)	2 IN /2 0UT	USB Audio 2.0 compatible Sampling rate: maximum 192kHz, Bit depth: 24-bit
Phantom power supply voltage	+48V
Power requirements		AC100-240V, 50/60Hz
Power consumption		36W	30W					22W
physical dimension（W x H x D）		444mm x 130mm x 500mm (17.5"x 5.1"x 19.7"）	444mm x 130mm x 500mm (17.5"x 5.1"x 19.7"）					308mm x 118mm x 422mm (9.6"x2.8"x11.6")
net weight		MG20XU: 7.1kg (15.7 lbs.) MG20: 6.9kg (15.2 lbs.)	MG16XU: 6.8kg (15.0 lbs.) MG16: 6.6kg (14.6 lbs.)					MG12XU: 4.2kg (9.3 lbs.) MG12: 4.0kg(8.8 lbs.)
Include attachments		Technical specifications, AC power cord, Cubase AI Download information (XU Models) Cabinet mounting kit (MG20XU, MG20, MG16XU, MG16)
Optional accessories		Cabinet mounting kit: RK-MG12 (for MG12XU, MG12 use), pedal switch: FC5 (XU model)
Operating temperature		0 to +40℃
