Dual Backup Desktop Network Delegate Microphone with Voting Function D7136

A speaking conference unit integrating speaking, sign-in, voting, microphone analog output backup, and tea service functions.

With dual backup function for microphone output, with 1-channel hand-in-hand conference system channel, 1-channel phantom 48V-powered microphone channel, and 2-channel links to work independently to ensure high reliability of system operation.

With 2m dedicated high-density cable, and 1 RJ45 universal network connector.

Adopt integrated square microphone rod (240mm in length, non-removable), electret cardioid directional condenser pickup microphone, with two-color indicator ring (red/green), red for speaking, green for applying for speaking.

Adopt 2.1" circular LCD display touch screen to display the working status of the unit in real time. The voting, rating, dynamic clock, language switching between Chinese and English, theme switching, tea service application, and SMS viewing can be completed through the display screen.

With 3.5mm stereo headphone jack for headphone connection to monitor the speech of other units.

Can adjust the microphone volume and headphone monitoring volume independently. Long press the V+ button to enter the microphone volume adjustment, and long press the V- button to enter the headphone monitoring volume adjustment.

With microphone on/off button, with a chairman priority button for the chairman unit. Can speak, sign in and number through the microphone on/off button.

With a unique ID for each conference unit. Long press the microphone on/off button to delete the ID number and reset to the first set of theme UI.

Come with 3 sets of theme UI, which can be switched freely through the theme interface.

Can apply for tea service through screen buttons, including pen, paper, manual service, tea, and coffee, to meet the needs of participants.

Display the ID number of the conference unit, the number of mics applying for speaking, the voting results, the number of attendees who have signed in and various operation information on the LCD screen.

Display the unit information in Simplified Chinese and English.

Combined with a camera, it can realize automatic camera tracking after set by the digital conference system host or PC control software.

Used in conjunction with the control host, the unit can realize the self-test function. The items to be tested include buttons, MIC, LED indicator, and LCD screen.

The unit is a passive device powered by the system host or PoE switch, with the input voltage of +48V.

Through the host settings, the chairman unit will be endowed with a priority function (to mute or turn off all delegate units) and a podium mode (the chairman unit is normally on).

The chairman unit has the authority to approve the application for speaking from the delegate unit.

The chairman unit has the function of initiating a voting.

The chairman unit can be turned on freely without being restricted by the number of speaking units.

The chairman unit has the priority function of having full control over the order of the conference.

There is no restriction on the location of the chairman unit when connected to the system.
