Digital Desktop Conference System Chairman Chairman Discussion Microphones D7253

  • Compliant with IEC 60914 international standard.

  • Pure speech conference mic.

  • Electret cardioid directional capacitive pickup with two-color indicator light (red/green), red for speaking, and green for applying for speaking.

  • Using a microphone rod with knob-type interface, and a mini microphone.

  • With two options for microphone rods: square and gooseneck. The square microphone rod is made of aluminum alloy, with 186mm in length; the gooseneck microphone rod is available in black and silver colors, with 315mm and 415mm in length optional.

  • The microphone rod can be dismounted during the adjournment for maintenance and storage.

  • With super strong anti-interference ability.

  • With MIC button, and chairman priority button for the chairman mic.

  • With button check-in function.

  • With a unique ID number for each conference mic.

  • Equipped with a camera, it can realize automatic tracking after setting by the digital conference system host or PC control software.

  • Equipped with the control host, the mic has a self-test function. The items to be tested include: buttons, MIC and LED indicator.

  • The mic is a passive device, powered by the system host or PoE switch, with input voltage of +48V.

  • Through the host settings, the chairman mic has the priority function (can mute or turn off all delegate mics), and the podium mode (the chairman mic is always on).

  • The chairman mic has the permission to approve the application for speaking from the delegate mic.

  • The chairman mic can be turned on freely without being restricted by the number of speaking mics, and its connection position is not restricted.

  • The chairman mic has the priority function of fully controlling the conference order.

Datasheet
Get Quotation
DETAILS
SPECS
Diagram
Digital Desktop Conference System Chairman Chairman Discussion Microphones
Digital Desktop Conference System Chairman Chairman Discussion Microphones
Digital Desktop Conference System Chairman Chairman Discussion Microphones
Digital Desktop Conference System Chairman Chairman Discussion Microphones
Digital Desktop Conference System Chairman Chairman Discussion Microphones

Specifications of Digital Desktop Conference System Chairman Chairman Discussion Microphones

Model

D7253/D7254

Structure Type

Desktop

Effective Frequency Range of Gain Limit (±3dB)

MIC to Host LINE

40Hz-16kHz

Static Power Consumption

3W

Maximum Power Consumption

≤5W

SNR

≥70dB

Crosstalk Attenuation

>75dB

Harmonic Distortion

<0.5%

Working Power

Host +48V power supply or +48V PoE switch

Unit Interface

Dante network interface

MIC

Microphone Type

Electret cardioid condenser

Sensitivity

-27dBV

Frequency Response

30Hz-20kHz (±3dB)

Input Impedance

2kΩ

MAX. SPL.

11dB(SPL)

Package Dimensions

(L×W×H) 485×265×135

Machine Dimensions

(L×W×H) 146×116×42

Gross Weight

2.2 KG

Net Weight

0.6KG
