Uses a 14dBi directional high-gain planar antenna in the 2.4-2.5G frequency band, with an input impedance of 50Ω.
Built-in 2.4G ultra-low power wireless module with a 48K digital audio sampling rate.
Utilizes 2.4G all-digital frequency-hopping modulation communication technology.
Includes a powerful built-in wireless audio transmission protocol, employing numerous coexistence mechanisms to prevent wireless conference units from external interference.
Built-in digital circuitry significantly amplifies the 2.4G wireless signal, enhancing communication stability for conference units.
Full-range communication with adaptive frequency hopping, forward error correction, and retransmission mechanisms to ensure data is never lost.
Connects directly to the host without the need for an external power supply, with both receiving and transmitting capabilities.
Radiation range of up to 40 meters in a straight line.
Equipped with a universal adjustable base for flexible installation on walls, desktops, and other locations.
The 2.4G Wireless Digital Conference System is a fully digital conference system specifically designed to integrate wireless discussion, camera tracking, and other functions. A single conference host can connect up to 255 wireless digital conference units. The system operates in the ISM frequency band using 2.4G full digital frequency-hopping (DSSS) modulation communication technology, enabling seamless coexistence with WiFi and featuring exceptional anti-interference capabilities. It employs true wireless digital transceiver separation and adaptive frequency-hopping technology, along with forward error correction and retransmission mechanisms, ensuring data is never lost. With encryption protection, the system prevents eavesdropping and unauthorized access, safeguarding meeting privacy. The system supports three speech modes: "First-In-First-Out," "Normal Mode," and "Chairman Mode." It allows up to four units to be activated simultaneously, with the speaking count adjustable from 1 to 4, enabling effective order management during meetings.
This system requires no complex cable installations and can be flexibly configured to meet meeting requirements without the need for frequency applications. Its advanced 2.4G frequency-hopping modulation communication technology and digital transmission technology significantly reduce the impact of interference signals on system operation. The unique 2.4G transmission characteristics, combined with its robust digital transmission technology and comprehensive communication protocols, ensure maximum security for meeting content. The system meets the needs of both standard fixed-installation conference rooms and portable meeting setups, offering a high-reliability conference solution that is both convenient and efficient.
Model | D6850 | D6859 | |
Frequency Response | 80Hz-16kHz (±3dB) | ||
LINE Output Voltage | 1000±100mV | ||
Channel BALANCE Output Voltage | 1000±100mV | ||
SNR | ≥70dB | ||
Total Harmonic Distortion | <0.5% | ||
Communication Interface | RS232 / RS422 | ||
Power Input | AC220V/50Hz | ||
Signal Booster | Modulation Method | DSSS Frequency Hopping | |
Power Supply Mode | Powered by the Host | ||
Transmission Power | 18dBm | ||
Receiving Sensitivity | -88dBm | ||
Radiation Range | 40 Meters in a Direct, Unobstructed Line | ||
Product Dimension (L×W×H) | 192×192×48mm | ||
Net Weight | 0.5kg | ||
Product Dimension (L×W×H) | 483×320×88mm | ||
Package Size (L×W×H) | 530×410×233mm | ||
Net Weight | 5kg | ||
Gross Weight | 6.5kg |
