Adopt UHF ultra-high frequency and true diversity reception to effectively avoid frequency loss and extend reception distance.
Adopt DPLL digital phase-locked loop multi-channel frequency synthesis technology.
Adopt infrared frequency pairing to easily and quickly synchronize the frequency of the transmitter and the receiver.
With display screen to display frequency, channel, squelch, level and others.
With balanced and unbalanced output ports to adapt to different connection needs.
With AF output, using “XLR” sockets for separate output and mixed output.
With built-in network audio acquisition module, which can realize wireless microphone audio signal network transmission.
Can control the network host by the buttons on the wireless microphone to play background music, initiate emergency paging, etc.
System Index | Parameters | |
Frequency Range | 632-661.25MHz | |
Number of Channels | 100 | |
Stepped Frequency | 250KHz | |
Frequency Stability | Within ±0.005% | |
Dynamic Range | 88dB | |
Maximum Frequency Deviation | ±48KHz | |
Audio Frequency Response | 125Hz-15KHz(±3dB) | |
SNR | ＞70dB | |
Distortion | ≤1 % | |
Working Temperature | -10℃-+40℃ | |
Effective Range | 150-300m (in open environment) | |
Package Dimensions (L×W×H) | 530×335×330mm | |
MAG6551 Gross Weight | 5.3kg | |
Receiver | Wireless Interface | BNC/50Ω |
Sensitivity | -100dBm | |
Spur Suppression | ≥75 dB | |
Function Display Method | Display Screen | |
Working Power | DC12V, 600mA | |
Package Dimensions (L×W×H) | 530×335×100mm | |
Machine Dimensions | 430×176×44mm | |
Gross Weight | 3.9kg | |
Net Weight | 2.3kg | |
Transmitter | Antenna Method | 1/4 wave whip antenna for the waistband transmitter, and built-in onboard antenna for the handheld microphone. |
Output Power | High power 14dBm; low power 6dBm | |
Spur Suppression | -60dB | |
Power Supply | 2 AA 1.5V alkaline batteries | |
Endurance | More than 10 hours at 14dBm; more than 15 hours at 6dBm. | |
Function Display Method | Display Screen | |
Handheld MIC Dimensions | 265×∅50mm | |
Remote MIC Dimensions | 268×∅51.5mm | |
Handheld MIC Net Weight | 0.45kg | |
Remote MIC Net Weight | 0.35kg | |
